OWNER'S MANUAL AA35 MIXER AMPLIFIER
20
SPECIFICATIONS
POWER OUTPUT
Max. Average Power @ 50Hz-20kHz with .5% THD (10-80kHz fi lter)
8Ω, 1kHz, 0.5% THD
35W RMS
TRANSFORMER OUTPUTS
25V 35W RMS
70.7V 35W RMS
8Ω 35W RMS
FREQUENCY RESPONSE
50Hz-20kHz
THD+N
.5% or less, at 1kHz, rated output
.1% or less, at 1kHz, 5W output
SENSITIVITY
Input 1 Mic .316 ~ 3.16mV (-50 ~ -70dBV)
Input 1 Telephone/Line 316mV (-10dBV) 10kΩ (optional 600Ω transformer available)
Input 2/3
316mV (10dBV) 10kΩ
OUTPUTS
Main: Transformer coupled, balanced, 8Ω, 25V, and 70.7V
Zone 2- 8Ω Unbalanced 1W
Zone 2- 600Ω Balanced 1.5V
OUTPUT REGULATION
Less than 2dB, no load to full load
SIGNAL TO NOISE RATIO
Mic >55dB
Line >55dB
Telephone >55dB
Input 2/3 >75dB
TONE CONTROLS
Bass ±10dB @ 100Hz
Treble ±10dB @ 10kHz
INDICATORS
Power, signal, peak
POWER CONSUMPTION
90W
DIMENSIONS
8.27" x 3.66" x 10.87" (210mm x 94mm x 276mm)
WEIGHT
10.2 lbs (4.64kg)
