16 TOLL FREE: 1-800-798-7398
PART PART NO.
1 Pre- Motor Foam Filter & Felt Filter XFF350
2 HEPA Filter XHF350
3 Dusting Brush 112FFJ
& Crevice Tool
4 Turbo Brush 1117FC
5 Turbo Brush 119FFJ
6 Bare Floor Nozzle 118FFJ
7 24” Crevice Tool 1124-FC
• Remove the dust cup and extension wand
and separate the detachable canister from the
motorized floor brush. Look in all 4 openings
for any blockages. (Fig. 28)
Motorized Floor Brush
• Detach the hose on the motorized floor brush
at the top by squeezing the tabs together
and pulling out, and at the bottom by pulling
out the connector. Inspect inside the 3 holes.
(Fig. 29)
Fig. 29
Maintenance - cont’d Ordering Parts
1
4 5
6
3 Fig. 28
7
2
