(2) Indoor unit

KS1852

1

1-7/32 (285)

1-25/32 (45)

39-3/16 (995)

(147.5)
5-13/16

(147.5)
5-13/16

7-23/32 (196)

1/8 (3)

Unit : inch (mm)

1-25/32 (45)

6-7/32

(172.5)

Remote control unit

2-2/5

(61)

25/32
(18.5)

Drain hose ø25/32 (18)

Narrow tube ø1/4 (6.35)

Wide tube ø5/8 (15.88)

Center of tubing
hole (2 places)
