15
Fresh Water Flush
Run a feed line from the domestic cold pressure water system to the 1/2 hose barb on the
fresh water flush assembly. This needs to be pressurized when the boat is unattended for
the fresh water flush system to function properly. The domestic fresh water pump must
be able to deliver 1.5 gallons per minute (6lpm) at 25 PSI. Connect the wiring harness
and heat shrink butt splices.
Brine Discharge
Route the Brine discharge from the
quick disconnect fitting to a location
above the waterline using the
supplied 5/8 hose.
Quick Disconnect Fitting
Fresh water from
boat’s pressure
water system
To Flush water Inlet
on pump module
manifold
