Chapter 2 Fitting and Connections
34
Chapter 2 Fitting and Connections
VF connector
Retaining catch
Viewfinder left-to-right
position fixing ring
Viewfinger front-to-back
position locking knob
Viewfinder left-to-right
position fixing ring
Using Accessories
Using the Viewfinder
Removing the Viewfinder
Remove any microphone from the viewfinder before
beginning.
1
Pull the viewfinder connector
out of the VF connector on the
front.
2
Loosen the viewfinder left-to-
right position fixing ring, then
pulling up the retaining catch,
slide the viewfinder out.
To fit the viewfinder
Reverse the removal procedure. (You need not hold
the viewfinder stopper up.)
Left eye adaptor
By fitting a left eye adaptor, you can use the
camcorder with your left eye to the viewfinder.
Note
You cannot stow the camcorder attached with a left
eye adaptor in the LC-421 Carrying Case.
For details, consult your Sony dealer.
Adjusting the viewfinder position
To adjust the viewfinder left-to-right position, loosen
the left-to-right fixing ring, and to adjust the front-to-
back position loosen the front-to-back position locking
knob.
