The following options are available in each menu. For details on navigating through menus, see
page 101.
Overview of the menus
Menu
[Display]
Parameters
[Display]
Settings Initial
setting
Auto Calibration
settings
[]
Auto Calibration start
[A.CAL START]
Calibration type
[CAL TYPE]
FULL FLAT, ENGINEER,
FRONT REF, OFF
FULL FLAT
Position
[POSITION]
POS 1, POS 2, POS 3 POS 1
Naming position
[NAME IN]
For details, see “Name Input (Naming
position)” (page 91).
Level settings
[]
Test tone a)
[TEST TONE]
OFF, FIX xxx b) , AUTO xxx b) OFF
Phase noise a)
[P. NOISE]
OFF, LH/FR, LH/RH, FL/RH,
FL/SR, SL/FL, SB/SL, SBL/SL,
SBR/SBL, SR/SB, SR/SBR, SR/SL,
FR/SR, FR/SL, CNT/FR, FL/CNT
OFF
Phase audio
a)
[P. AUDIO]
OFF, LH/FR, LH/RH, FL/RH,
FL/SR, SL/FL, SB/SL, SBL/SL,
SBR/SBL, SR/SB, SR/SBR, SR/SL,
FR/SR, FR/SL, CNT/FR, FL/CNT
OFF
Front left speaker level a)
[FL LEVEL]
FL –10.0 dB to FL +10.0 dB
(0.5 dB per step)
FL 0 dB
Front right speaker level a)
[FR LEVEL]
FR –10.0 dB to FR +10.0 dB
(0.5 dB per step)
FR 0 dB
Center speaker level a)
[CNT LEVEL]
CNT –20.0 dB to CNT +10.0 dB
(0.5 dB per step)
CNT 0 dB
Surround left speaker level a)
[SL LEVEL]
SL –20.0 dB to SL +10.0 dB
(0.5 dB per step)
SL 0 dB
Surround right speaker level a)
[SR LEVEL]
SR –20.0 dB to SR +10.0 dB
(0.5 dB per step)
SR 0 dB
Surround back speaker level a)
[SB LEVEL]
SB –20.0 dB to SB +10.0 dB
(0.5 dB per step)
SB 0 dB
Surround back left speaker
level
a)
[SBL LEVEL]
SBL –20.0 dB to SBL +10.0 dB
(0.5 dB per step)
SBL 0 dB
Surround back right speaker
level
a)
[SBR LEVEL]
SBR –20.0 dB to SBR +10.0 dB
(0.5 dB per step)
SBR 0 dB
Front left high speaker level a)
[LH LEVEL]
LH –20.0 dB to LH +10.0 dB
(0.5 dB step)
LH 0 dB
Front right high speaker level a)
[RH LEVEL]
RH –20.0 dB to RH +10.0 dB
(0.5 dB step)
RH 0 dB
