SMOOTH 9.25X MOTORIZED TREADMILL
Visit us at: www.smoothfitness.com
5
HARDWARE COMPARISON CHART
Hardware chart:
For your convenience, we have identified the hardware used in the assembly of this product. This chart is provided to help
you identify those items that may be unfamiliar to you.
NO. DESCRIPTION QTY.
9
Console Support Fixing
Plate
2
11 M6 x 15mm Screw 4
16 #8 x 25mm Screw 8
17 Handlebar Fixing Plate 2
18 M8 x 50mm Allen Head Bolt 6
19 M8 x 15mm Allen Head Bolt 4
A Wrench 1
B Screw Driver 1
C Allen Wrench 1
11 16
18
19
C B A
9
17
MILLIMETERS
