Smooth Fitness 9.25X User Manual
Page 13
SMOOTH 9.25X MOTORIZED TREADMILL
Visit us at: www.smoothfitness.com
13
ASSEMBLY
STEP 2:
NOTE: YOU WILL NEED THE HELP OF ANOTHER PERSON IN ORDER TO COMPLETE STEP 2 OF THE ASSEMBLY
PROCEDURE.
First make sure to connect the wires. Then, simply have one person hold the Uprights (30 and 36) in place on
the Base Frame (55) while the other secures it with four M8 x 15mm Allen Head Screw (19).
19
30
19
55
