Smooth Fitness 9.25X User Manual
Page 12
SMOOTH 9.25X MOTORIZED TREADMILL
Visit us at: www.smoothfitness.com
12
ASSEMBLY
STEP 1:
Remove your treadmill from the carton and place it on the floor in an open area as shown in FIG 1.
Then remove the Handlebars and place them out of the way for now, as shown in FIG2.
Attach the
Console Support Tube
(7) to Upright – Left (30) and Upright – Right (36) with Console Support Tube Fixing Plate
(9) and M8 x 50mm Allen Head Bolt (18).
FIG.1 FIG.2
18
3
7
30
9
36
9
