TV (Front view)
Quick guide
TV (Rear view)
NOTE
• Only if you use an
active terrestrial
antenna, select
“On (5V)” under
“Supply Voltage”.
(See page 18.)
AC INPUT terminal
OPC sensor
Remote control sensor
B (Standby/On) indicator
OPC indicator
a (Power button)
b (Input button)
i (l/k) (Volume buttons)
P (s/r)
(Programme [channel] buttons)
SLEEP indicator
EXT 2 (RGB) terminal
EXT 3 terminals
Headphone jack
EXT 1 (RGB) terminal
EXT 5 (HDMI/AUDIO)
terminals
Antenna input terminal
(DVB-T 5V=/80 mA)
OUTPUT (Audio) terminals
EXT 4 terminals
RS-232C terminal
COMMON INTERFACE slot
EXT 6 (HDMI) terminal
