Sanyo DC Inverter Split System XHS1271 - Manual (Page 12)

Indoor Unit (Body) XHS1271
Indoor Unit (Panel) PNR-XS1872
2-2. Major Component Specifications
2-2-1. Indoor Unit
MPZN-12V ... 2
Flap Motor
Type Stepping Motor
Rating
Model ... Q'ty
Coil Resistance Ohm
(Ambient Temp. 77 °F (25 °C))
Each Pair of Terminal : 380 +/- 7%
DC 12V
PLD-12115ST-1 ... 1
AC115V, 60Hz
10.8
101 +/- 10% Coil Resistance
Model ... Q'ty
Rating Voltage, Hz
Input
Drain Pump
Ohm
W
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Thermal Fuse
293 (145)
(Ambient Temp. 68 °F (20 °C))
Safty Device
Open
Type
°F (°C)
Aluminum Plate Fin / Copper Tube
2
18.1
2.94 (0.273) Face Area
Coil
Rows
Fins per inch
Heat Exchanger Coil
ft 2 (m 2 )
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Yes
Control PCB
Control Circuit Fuse
Controls
Part No.
Microprocessor
250V 3A
CB-XHS1271
1 ... D12-5/8 / L5-3/4 (D322/L147)
RCS-7MHVPSW4U
Turbo
DC Motor
SIC-72FV-B623-1 ... 1
8
-
DC160V / 23W
470 / 520
Internal Controller
Yes
-
-
Fan
Remote Control Unit
Q'ty ... Dia. and Length
Type
inch (mm)
Fan Motor
Rating Voltage / Nominal Output
Coil Resistance
Rough Measure RPM (Cool / Heat)
Type
Model ... Q'ty
No. of Poles
Safety Device
Type
Over- Current Protection
Over- Heat Protection
(Ambient Temp. 68 °F (20 °C))
Run Capacitor Micro F
VAC
Ohm
12
