Bass Attack Front Panel Layout
1 HARMONICS - Control knob used to adjust
the amount of tube-emulation from warmth
to dirt.
2 MIX – Control knob used to adjust the blend
between the dry signal and Harmonics sig-
nal.
3 TREBLE - Control knob used to boost or cut
the high frequencies.
4 SHAPE - Used to adjust the renowned
Hartke one-knob equalizer circuit with a
preset curve that can be swept through the
wide frequency range.
5 LEVEL – Used to adjust the overall Output
volume.
5
6 BRITE – Used to adjust the extreme high
frequencies.
7 ON/OFF LED –RED LED, which illumi-
nates to indicate that the Harmonics, Mix
and Brite functions are engaged.
8 ON/OFF - Footswitch used to engage the
Harmonics, Mix and Brite functions.
9 SHAPE switch – Footswitch used to
engage the Hartke Shape circuit.
10 SHAPE LED - RED LED, which illuminates
to indicate that Hartke Shape circuit is
engaged.
11 BASS - Control knob used to boost or
cut the low frequencies.
1 2 3 4 5
6
7
8 9
10
11
