MAIN UNIT PART NAMES (Continued)

Removing the Back Cover

■ Before connecting cables and cords to the rear terminals, remove the back covers. Push

in the tabs and pull out the back covers carefully.

■ To mount the cover, insert the 2 hooks on the bottom of the cover into the cabinet and

press on the upper part of the back cover until the tab locks in place with a click.

Listening with Headphones

■ Plug the headphone mini-plug into the HEADPHONE jack located on the rear of the TV set.

Note:

• Headphones are not included in the supplied accessories.

• No sound is heard from the main unit speakers when a headphone mini-plug is connected into the HEADPHONE jack.

▼ On-screen display

Adjust the sound volume
using VOL (e)/(f) on the
remote control.

Headphones

AUDIO

AV- IN4

VIDEO

S-VIDEO

HEAD

PHONE

Rear terminal

VOLUME
