Sony CPD-120AS User Manual
Page 9

9
GB
!§
!¶
!•
!ª
@º
@¡
@™
@£
@¢
AC IN connector
2
Audio plug (green)
h MIC plug (red)
;
Video signal cable
(blue)
USB downstream
connector
h Microphone jack
2
Headphones jack
Tilt-Swivel
USB upstream
connector
Connect the supplied power cord (page 12).
Connect to the computer’s speaker output
(page 11).
Connect to the computer’s microphone input
(page 11).
Connect to the computer’s video output
(page 11).
Connect to a USB device (page 11).
Connect a microphone (not supplied).
Connect headphones (not supplied). The
speakers are turned off when headphones are
connected.
Adjusts the angle of the display (page 14).
Connect to the computer’s USB ports when
using a USB (universal serial bus) device
connected to the display (page 11).
Functions of Controls
