11 GB Getting Started
p CPD-120AS
p CPD-220AS
✔
Note on handling the video signal cable
Do not touch the pins of the video signal cable.
✔
Note on USB ports
USB ports are included to provide state-of-the-art technology. Until USB support is
available at the operating system level, you must supply drivers to use USB devices. You
can upgrade your operating system to a version that supports USB at the operating system
level once a version becomes available.
See the manual that came with your USB device for more information on setting it up and
using it.
Continued to the next page ➔
Computer
Red (to microphone
connector)
Blue (to display
connector)
Green (to speaker
connector)
to
Computer
Red (to microphone
connector)
Blue (to display
connector)
Green (to speaker
connector)
to
to USB port
to USB port
