28 GB
Specifications
Picture tube
CPD-120AS: 0.25 mm aperture grille pitch, 15 inches
measured diagonally (13.9” viewable),
90-degree deflection, AR coating
CPD-220AS: 0.25 mm aperture grille pitch, 17 inches
measured diagonally (16.0” viewable),
90-degree deflection, AR coating
Viewable image size
CPD-120AS: Approx. 284
×
212 mm (w/h) (11 1 /
4
×
8 3 /
8
inches) 13.9” viewing image
CPD-220AS: Approx. 327
×
241 mm (w/h) (12 7 /
8
×
9 1 /
2
inches) 16.0” viewing image
Max resolution Horizontal: Max. 1280 dots
Vertical: Max. 1024 lines
VESA standards 640
×
480 at 85 Hz
800
×
600 at 85 Hz
1024
×
768 at 85 Hz
1280
×
1024 at 60 Hz
Deflection frequency
Horizontal: 30 to 70 kHz
Vertical: 50 to 120 Hz
Speaker Left, right: 3.5 W x 2, Sub-woofer: 10 W
50 to 20 kHz
Microphones Uni-direction, electret condenser microphone
Microphones output
Miniplug
Audio input Stereo miniplug, input impedance 47 k
Ω
, input level
0.7 Vrms typical
Headphones output
Stereo minijack, 4 mW + 4 mW at 16
Ω
Microphones input
Minijack, plug-in-power
USB pass-through
Upsteam
×
1, downstream
×
1
Controls Contrast/Audio level/Picture enhancement/
Brightness/Bass Boost/(Audio level)/H.Size/V.Size/
Pincusion/Color tempeature/Audio muting
Specifications
