CONNECTIONS
Turn off the power for all components before connecting them.
Be sure to carefully read the Instruction Manual for all equipment being connected to the digital video recorder.
If the connections are incorrect, smoke or operating malfunctions may result.
Basic connections (DSR-3016 model)
Nine cameras can be connected to the DSR-3009 model.
Connecting high image quality (S-VHS) video equipment
Connecting to an Amplifier
