SCREEN SETTING
9
Press the EXIT/OSD button.
The display returns to the normal screen.
Example 3: To set a 5-second interval for the
automatic switching of main monitor
images and to prevent automatic
switching from occurring when it is not
required, such as when using the timer
function.
1
Set the timer setting for both TIMER A and TIMER B in the
TIME PERIOD SET menu. (See page 46.)
Set both TIMER A and TIMER B.
2
Use the jog dial to move the cursor to SEQUENCE, and then
turn the shuttle dial clockwise.
“1S” flashes.
3
Use the jog dial to change the SEQUENCE setting to “ INDIV.” ,
and then turn the shuttle dial clockwise.
The cursor moves to SEQUENCE SET.
4
Turn the shuttle dial clockwise.
The SEQUENCE SET sub-menu appears.
5
Turn the jog dial to select MAIN MONITOR, and then turn the
shuttle dial clockwise.
“1S” flashes.
6
Use the jog dial to set “ 5S” , and then turn the shuttle dial
clockwise.
The cursor moves to MAIN MONITOR SET.
Display examples:
•
1 – 30S: Sets the automatic switching time for the main
monitor.
•
INDIV. : Select when setting individual switching times for each
camera for the main monitor.
7
Turn the shuttle dial clockwise.
The MAIN MONITOR SET sub-menu will be displayed. This
sub-menu screen is used to select whether the images from
cameras 1 to 16 are displayed or not displayed for the time set by
the timer setting (T-1).
8
Turn the shuttle dial clockwise, use the jog dial to select
“ T-1” , and then turn the shuttle dial clockwise.
The cursor moves to 01.
9
Use the jog dial to move the cursor to CAMERA 1 (01), and
then turn the shuttle dial clockwise.
“ON” flashes.
10
Use the jog dial to set “ OFF” , and then turn the shuttle dial
clockwise.
Repeat the above procedure to set cameras 2 (02) through to 8
(08) to “OFF”.
11
Use the jog dial to move the cursor to T-1, and then turn the
shuttle dial clockwise.
EXIT/OSD
TIME PERIOD T1 T2 T3 T4
TIME PERIOD A 00:00 00:00 00:00 00:00
TIME PERIOD B 00:00 00:00 00:00 00:00
SELECT WEEK OF TIME PERIOD
SEQUENCE TIME PERIOD A
MASK TIME PERIOD A
MOTION TIME PERIOD A
1.MULTI SCREEN : NORMAL
MULTI SCREEN SET ->
2.SEQUENCE : 1S
SEQUENCE SET ->
3.MASK : OFF
MASK SET ->
MAIN MONITOR : 1S
MAIN MONITOR SET ->
MON.2 : 1S
MON.2 SET ->
QUAD : 1S
INDIVIDUAL INTERVAL SET ->
84 English
