17
RS-232C Command List
Camera Setup Readout from a
List
Read Request [RMEM]
Sends the relative address and the data, in order, from
the beginning of the Camera Setup Memory area.
Host Computer
Camera
[RMEM]
t
T
[S00_
**
]
**
are assumed to be 8bit(LSB: b0)
b1=0: AGC OFF,
b1=1: AGC ON
b3=0: Shutter Manual, b3=1: Shutter Auto
T
[S01_
**
]
**
= AGC Max Gain
00: 6dB, 01: 12dB, 02: 18dB
T
[S02_
**
]
**
= Gain
00: 0dB – 12h: 18dB
T
[S03_
**
]
**
= AE Compensation
00: under – 80h: Standard – FFh: over
T
[S04_
**
]
**
= Shutter Speed(1)
The first digit of the 00,01h Shutter Speed variable’s 3 digits
T
[S05_
**
]
**
= Shutter Speed(2)
The last two digits of the 00 – FFh Shutter Speed variable’s 3 digits
T
[S06_
**
]
**
= [E3
**
]
The last two digits of the most recently received [E3**] command
T
[S07_**]
**
= [E4
**
]
The last two digits of the most recently received [E4**] command
T
[S08_
**
]
**
= CCD Iris Max Speed
00: 1/250 – 04h: 1/4000 – 08h: 1/100000
T
[S09_
**
]
**
= AE Speed
00: slow,02: norm,04: fast
T
[S0A_
**
]
**
= White Balance Mode
00: AWB,01: ATW,03: manual,04: 3200K,05: 5600K
T
[S0B_
**
]
**
= ATW Speed
01: slow,02: norm,03: fast
T
[S0C_
**
]
**
= R-Gain
00: min – 80h: Standard – FFh: max
T
[S0D_
**
]
**
= B-Gain
00: min – 80h: Standard – FFh: max
T
[S0E_
**
]
Not Defined
T
[S0F_
**
]
Not Defined
T
[S10_
**
]
**
= Pedestal
71h: min – 8Fh: Standard – FFh: max
T
[S11_
**
]
**
= Gamma
00: OFF, 80h: ON
T
[S12_
**
]
**
= Memory Bank
00: Factory, 01: Bank A, 02: Bank B
T
[S13_
**
]
**
= Sharpness
7Ah: min – 89h: Standard – FFh: max
T
[S14_
**
]
Not Defined
T
[S15_
**
]
Not Defined
T
[S16_
**
]
**
= Picture
00: Nega, 01: Norm
T
[S17_
**
]
**
= Output
00: Y/C, 01: VBS
T
[S18_
**
]
**
= H-Phase (VS mode)
00: Phase Delayed – 80h: Standard – FFh: Phase Advanced
T
[S19_
**
]
**
= H-Phase (HR/VR mode)
00: Phase Delayed – 80h: Standard – FFh: Phase Advanced
T
[S1A_
**
]
Not Defined
T
[S1B_
**
]
Not Defined
