Instructions for the user
12
6.4 Triple cooking zones
To activate heating of the triple cooking zone, once power 9 of the dual cooking zone is reached by
following the instructions provided in paragraph "6.3 Dual cooking zones", press the
again. The
maximum power of the triple cooking zone is now activated, and the LED indicating the operating power
remains fixed. Press the symbols
and to adjust the power of the triple cooking zone to the desired
value.
6.5 Cooking zone lock-out
The cooking zone lock-out function is a user safety function. It locks out the cooktop controls to prevent
the ceramic cooking zones from being turned on accidentally.
Hold down
for 1 second to lock out the cooktop. The cooktop can be reactivated by holding down
again for 1 second.
6.6 Timer
Some models are equipped with a 1 to 99 minute cooking timer.
To use the timed cooking feature, first set the power level by following the instructions given in
paragraphs "6.2 Single cooking zones" and "6.3 Dual cooking zones".
Now, with the cooktop NOT locked out (if it is locked out, press the
key to enable the functions), press
the symbol .
Between the symbols and of the first active cooking zone, a LED light will turn on to indicate that
the minutes to be set will refer to the operation of that particular zone.
The minutes of automatic operation for the cooking zone can be increased or decreased by using the
and
keys beside .
After 5 seconds since the last time it was pressed, the timer will start and the cooking zone will operate
until the display above the symbol
reaches 0.
At this point the cooking zone will automatically turn off.
It is also possible to use the timed cooking function on more than one cooking zone at a time.
Once the timer is set on the first zone, press
key to shift the timer controls over to the next active zone
(the LED light between the symbols and of the second active cooking zone will be activated) and
then set the cooking time as described previously.
When the timed cooking is active on several cooking zones at the same time, the display between the
symbols
and of the cooking zone will alternatively turn on and at the same time the minutes
display found on the symbol will show the time remaining for the zone with the LED light on.
6.6.1 Modifying the data set
During timed cooking, every time the and symbols are pressed increases or decreases the power
of the cooking zone.
To change the remaining time of a zone, press the
key until the LED light in the cooking zone turns
on. The operating time can now be modified by means of the and symbols of the timer.
6.7 Residual heat
Each cooking zone is equipped with a residual heat warning device. After any zone is switched off, a
flashing "
" may appear on the display. This warns that the concerned cooking zone is still very hot.
Cooking can be restarted while the LED is flashing; proceed as described in points "6.2 Single cooking
zones / 6.3 Dual cooking zones".
