Sierra Wireless RAVEN IDEN 20070914 - Manual (Page 3)

Raven iDEN
3 20070914
Tools Required
• Small Phillips screw driver ‐ The Phillips screw driver is
the one which is also called a plus (+) or X screw driver.
• Slim stylus ‐ A PDA stylus, an unbent paperclip, or other
such item.
1. Opening the Case
a. Unplug the Raven power and all cables.
b. Using a small phillips head screw driver, remove the
screws on the back of the Raven.
c. Slide the case off of the Raven and set it aside.
Figure 0-1: Partially removed case
2.
a. Carefully remove the SIM card from the card you got
from TELUS.
3. Ejecting the SIM tray
Tip: The button is between two boards.
Figure 0-2: SIM tray button
