ENFORCER Wireless Request-to-Exit Plates
2 SECO-LARM U.S.A., Inc.
Built-in RF transmitter:
- Powered by 9VDC (battery included).
- Range up to 250 feet. 315MHz.
- Over 68 billion (6.8x10 10 ) possible codes.
- LED to indicate transmission and low battery.
Stainless-steel single-gang or slim-line plate.
Available in 2 different button configurations:
- Green 2” square
- Green, small, square
English “Push to Exit” and Spanish
“Presione para Salir” messages included.
Specifications:
The ENFORCER Wireless RF Request-to-Exit Buttons are the ideal solution for difficult Access
Control installations. The RTE plates combine the very best of SECO-LARM, flexible wireless
solutions and reliable access control. The RTE plates are perfect for cement or brick walls, or any
other location where it is difficult to run wires.
Introduction
:
Features
:
Dimensions:
1 1 /
2
”
(38mm)
4 1 /
2
”
(114mm)
2 3 /
4
”
(70mm)
2 1 /
4
”
(57mm)
Operating frequency 315 MHz
Operating voltage 9VDC
Battery life 1-2 years (depending on use)
Dimensions
Single-gang 4 1 /
2
" x 2 3 /
4
" x 2 1 /
4
" (114 x 70 x 57 mm)
Slim-line 4 1 /
2
" x 2 1 /
4
" x 1 1 /
2
" (114 x 57 x 38 mm)
Detail: Wireless Request-to-Exit Plates
Switch
9V Alkaline
Battery
LED indicator
Request
button
Battery clip
Wireless
transmitter
SD-8202GT-PEQ
(shown)
Red=Low Battery
Red=Low Battery
Red=Low Battery
ENFORCER ®
