Page 13
1-2 Granulator Specifications
Table 1: Granulator Specifications
EX909 EX913 EX918
Cutting Circle 9.7” (247 mm) 9.7” (247 mm) 9.7” (247 mm)
Throughput 30 lbs./hr (14 kg/hr) 40 lbs./hr (18 kg/hr) 50 lbs./hr (23 kg/hr)
Cutting Chamber 9” x 9” (229 mm x 229
mm) 9” x 13” (229 mm x 330
mm) 9” x 18” (229 mm x 457
mm)
Rotor Knives Hardened 8620 alloy
steel Hardened 8620 alloy
steel Hardened 8620 alloy
steel
Bed Comb Reversible 1/4” (6.4 mm)
comb Reversible 1/4" (6.4 mm)
comb Reversible 1/4" (6.4 mm)
comb
Discharge Bin 0.70 cu. ft. (.0198 cu.
meters) 0.85 cu. ft. (.0241 cu.
meters) 1.00 cu. ft. (.0283 cu.
meters)
Motor 1 hp (.75 kW) 2 hp (1.5 kW) 2 hp (1.5 kW)
Drive Cyclodial speed reducer
– 34rpm Cyclodial speed reducer
– 34rpm Cyclodial speed reducer
– 34rpm
Electrical
Components Start/stop pushbutton Start/stop pushbutton Start/stop pushbutton
Controls NEMA type 12 NEMA type 12 NEMA type 12
Feed Height 52” (1321 mm) 52” (1321 mm) 52” (1321 mm)
Length 25.25” (641 mm) 25.25” (641 mm) 25.25” (641 mm)
Width 19” (483 mm) 23” (584 mm) 28” (711 mm)
Weight 550 lbs (250 kg) 650 lbs (295 kg) 750 lbs (341 kg)
1-3 Standard Features
Standard features of the EX Series Granulator are
• 34 RPM rotor speed
• 230 or 460 voltages
• Segmented rotor comb design
• Timing belt drive system with taper lock bushings
• Totally-enclosed fan-cooled gear motor
• Front hopper cleanout door
• NEMA 1 drop-down rear access electrical enclosure with fused
disconnect switch
• Start-stop control button mounted on NEMA 12 box
• Front-access bed comb cam adjusting system
• 8620 heat treated cutter segments
• Manual discharge bin
• Positive break safety switch to interlock hopper and chute doors
