4 SMOOTH CE3.6 ELLIPTICAL
SUPPLIED HARDWARE
This list identifies the hardware you will use to assemble the product. To help distinguish between the various types of
screws and bolts, use the scale below to measure them and compare them to the sizes listed.
No. Description Qty.
701 726
728 730
731
709
710
708
B
C
729
D
E
732
722 719
A
701 M14x91mm Bolt 2
708 M8x60mm Bolt 2
709 M10x94mm Bolt 2
710 M8x65mm Bolt 2
719 M14 Nut 2
722 8x21x2mm Cup Washer 2
726 4x19mm Screw 19
728 4x12mm Screw 8
729 M10 Nut 2
730 4x50mm Bolt 1
731 10.5x28x2mm Cup Washer 2
732 4x15mm Screw 8
A Spanner 1
B 5mm Allen Key 1
C 8mm Allen Key 1
D Wrench 1
E Screwdriver 1
MILLIMETERS
