Instruction for the user
16
5 DESCRIPTION OF CONTROL PANEL
All the oven controls are grouped together on the front panel. The table below provides a description
of the symbols used.
FRONT RIGHT BURNER CENTRAL BURNER
BACK RIGHT BURNER GAS OVEN THERMOSTAT KNOB
BACK LEFT BURNER OVEN LIGHT / ROTISSERIE / GRILL
SWITCH
FRONT LEFT BURNER ELECTRIC OVEN FUNCTION KNOB
BACK CENTRAL BURNER OVEN FUNCTION
FRONT CENTRAL BURNER
If the cooker is equipped with an electronic programmer, before using the oven make sure that the
symbol ; appears on the display. See paragraph “8.1 Clock adjustment”.
COOKING HOB BURNER COMMAND KNOB
The flame is lit by pressing the knob and turning it anticlockwise to minimum
flame . To adjust the flame turn the knob between maximum ( ) and minimum
( ). The burner goes out when the knob is returned to the position .
GAS OVEN THERMOSTAT KNOB
(CERTAIN MODELS ONLY)
This knob is used to ignite the gas burner inside the oven. The cooking
temperature is selected by turning the knob anticlockwise to the desired setting,
between Min. and 275°C.
For information on how to ignite the gas oven, see point “ 7.3 Use of the gas oven ”.
For information on how to ignite the grill burner, see point “7.5 Use of the gas grill ”
OVEN LIGHT / ROTISSERIE / GRILL SELECTOR KNOB
(CERTAIN MODELS ONLY)
This knob allows the user to activate the Grill / Rotisserie function or to switch on
the light inside the oven to check the point reached in cooking the food.
CAUTION: IT IS NOT POSSIBLE TO OPERATE THE GAS OVEN AND THE
GRILL / ROTISSERIE SIMULTANEOUSLY.
