SCL Series
● REEL DIMENSION
Case Size
reference
180mm(7") reel 330mm(13") reel
J 4,000pcs -
R 3,000pcs -
S, T 2,000pcs 8,000pcs
V, W 500pcs 2,500pcs
Tape
Width
A±2
(±0.079)
N Min.
C±0.5
(±0.020)
D±0.5
(±0.020)
B±051
(±0.020)
t+0.5
(±0.020)
R
8mm
ш178
(7)
ш70
(2.756)
ш13
(0.512)
ш21
(0.827)
2
(0.079)
10
(0.394)
2
(0.079)
0.99
(0.039)
12mm
ø60
(2.362)
14
(0.551)
8mm
ш330
(13)
ш80
(3.150)
ш13
(0.512)
ш21
(0.827)
2
(0.079)
10
(0.394)
2
(0.079)
0.99
(0.039)
12mm
14
(0.551)
