-63
Appendix
Dimensions
Units: inches (mm)
Side View Side View Top View
Rear View
Front View
Bottom View
M4
M4
M4 M4
9
/ 64
(3.25)
11
7
/ 64
(282)
1
/ 16
(1.5)
2 11 / 64 (55.05)
12 7 / 32 (310)
1 59
/ 64
(48.5)
3 33
/ 64
(89)
13
/ 64
(5)
2 3
/ 16
(55.5)
3 15 / 16 (99.95)
5 7 / 64 (129.5) 5 7 / 64 (129.5)
5
/ 8
(15.5)
9
/ 16
(14)
4 3
/ 16
(106.3)
8 9
/ 32
(210.3)
8 7
/ 8
(225.3)
1 7 / 32
(30.9)
1 5 / 32
(29.1)
1 7 / 32
(30.9)
1 3 / 4
(44.1)
