Rugged Design and Small Size
Uniquely designed for harsh outdoor environments, and handheld size the SPP-R200 is ideal
for printing delivery receipts and invoices on the go.
BIXOLON SPP-R200, a small and lightweight mobile receipt printer.
A prudent choice for any mobile receipt printing application where you need fast, on-demand printing with speeds
up to 80mm per second (3.15inches/sec). The SPP-R200 also utilizes a long-life Lithium-ion battery with a 8 hour
continuous operation life (approx. 10 ø40mm rolls per battery charge, stand-by : 14 hours). The magnetic card
reader integrated into the printer allows credit cards to be processed immediately at the point of transaction,
increasing customers’ sense of security since the credit card does not leave their sight.
MAIN FEATURES
FOR THE SPP-R200
SPP-R200
Compact yet Rugged SPP-R200M (With MSR) SPP-R200 (Without MSR)
The BIXOLON Mobile Printer SPP-R200
is a small, lightweight mobile receipt
printer that brings user convenience
and functionality to any mobile receipt
printing applications such as;
Mobile POS / Retail
Hospitality
Parking Citations
Deliveries
Onboard Transportation
Field Repairs / Installation
Warehouse/Logistics
Utility billing / Meter Reading
Intuitive wireless capability, long battery
life and handheld size that wears
perfectly on a belt strap or leather case,
the Compact yet Rugged, BIXOLON
Mobile Printer SPP-R200 fully satisfies the
anytime and anywhere demands of
today’s mobile commerce.
All you need in one package!
An AC adapter(Charger) with the power code
A long lasting Lithium-ion battery
Portable device, Belt Strap, suited
for outdoor usage
A roll of receipt paper (Thermal) to get
started printing right away
A quick-reference guide sheet
An installation CD including the drivers, all
software programs, test samples and the
user� guide book
RUGGED DESIGN
• Damage-resistance to multiple drops
of up to 1.2 meters (4 feet)
• Damage-resistance material
for printer housing
• Rubber over-molding to
prevent from damage
to weak points of the
printer
Fast Printing Speed
To speed up customer transactions without sacrificing performance, the SPP-R200 prints texts
and graphics at a consistent speed of 80mm per second. Reduced data processing time has
been achieved by utilizing a more powerful CPU; increases in performance have been made
by upgrading mechanical components and optimizing software.
• CPU : 32 bit
• Flash Memory : 16 Mbit (NV Image: 256KBytes)
• RAM : 64 Mbit (SDRAM)
• Buffer : 128 KByte
SMALL AND LIGHTWEIGHT DESIGN
• 79.5mm (W) x 126.7mm (L) x 43.6mm (H)
(3.1" x 5.0" x 1.7")
• 0.65lbs (293g) including
paper roll, battery
Damage-resistance material
Rubber over-molding Handheld size
Magnetic Stripe Reader (MSR)
The Magnetic card reader integrated into the printer allows credit cards to be processed
immediately at the point of transaction, increasing the customers’ sense of security since the
credit card does not leave their sight.
• One touch open (Patent applied)
• All track conditions supported by VMSM
Other value-added features
Customer Oriented Software Tools
The SPP-R200 is supported by a rich pool of utility software. The Firmware download tool, NV
image tool and Virtual Memory Switch Manager (VMSM) are available with more software
being added in the future. These new customer oriented utilities
enable the users to directly access logo download, code page
selection, firmware download and the other printer settings more
easily and with no Hardware setting changes.
NV IMAGE MANAGER
• For Logo download (Update available)
• Printing Mode
(Receipt Mode or Label mode)
• User-defined fonts type and size
• Default code page
• Printing Density
(Value range: 80 ~ 130%)
• Printing Speed
(50mm/sec, 80mm/sec)
• Beeps for Roll Paper End
• MSR Trigger
• Auto Power Off Time
(0 ~ 90 minutes)
• Auto Power Saving Time
(10 ~ 255 seconds)
• Default Interface
• Authentication Encryption
• Bluetooth connection Mode
• PIN Code and Printer Name
(Max value is 12 digit or alphabet)
VIRTUAL MEMORY SWITCH MANAGER (VMSM)
TO DESIRED SETTINGS
Long lasting Lithium-ion Battery
SPP-R200 utilizes a long-life lithium-ion battery with a 8 hours operation life
(approx. 10 ø40mm rolls per battery charge, Stand-by : 14 hours) of 203 dpi (8dots/mm)
thermal printing on a single charger.
LITHIUM-ION BATTERY (7.4V 1,200mAh)
• Operation hours: 8 hours
(approx. 10 ø40mm of rolls printing/charge)
• Standby hours: 14 hours
BATTERY STATUS INDICATOR
• Low battery alarm support
• 4 step battery indicator and connectivity status
SMART BATTERY MANAGEMENT
(Monitors battery for longer life and performance)
• Sleep or Auto Power OFF Mode
• Sleep or Auto Power OFF time set by Virtual
Memory Switch Manager
Full (3 LEDs) 2 LEDs 1 LED Low battery alarm
*MSR : Factory Option
Single Track Track 1 Track 2 Track 3
Dual Track Track 1 • 2 Track 2 • 3 -
Triple Track Track 1
•
2
•
3 - -
One touch open MSR Reading
• Various Interface communication and interface capabilities
- Serial/USB - Bluetooth with high communication speed (115,200 bps)
• Intuitive LEDs
• Portable device suited for outdoor usage
- Belt Strap (Default) - Leather Case (Optional)
• 30 code pages included in the standard firmware (no update necessary, to be set by VMSM)
• 203 dpi printing
• WinCE 4.2, WinCE 5.0, Win95/98/ME/2000/NT/XP/2003 Server/VISTA, OPOS drivers available
FIRMWARE MANAGER FOR PRINTER & BLUETOOTH INTERFACE
• For firmware download (Update available)
