15 05/05 ID# M866041
14.
A.
B.
15.
Apply height indicator
labels (32 & 31) to height
indicators (30).
Attach height indicators to lower yoke in area shown by tapping
screws (29) into place with a rubber mallet.
2. 4. 3. 1.
Install net (4) to rim as shown.
7
8
9
10
7 8 9 10
7 8 9 10
7 8 9 10
7 8 9 10
IMPORTANT!:
NOTE ORIENTATION
OF HEIGHT
INDICATORS:
10’ MARK SHOULD
FACE AWAY FROM
BACKBOARD.
Set-up For Right Side Set-up For Left Side
7 8
91
0
29
29
32
31
30
30
