1
Table of Contents
Adjustments.........................................................7
Skid Shoe Adjustment .....................................7
Spring Tension.................................................7
Lift Height Adjustment .....................................7
Downward Pressure Adjustment .....................7
Initial Setup & Assembly
Dozer Components..........................................9
Hitch Components .........................................10
Assemble Blade.............................................11
Assemble & Install Hitch ................................11
Install Pushbar...............................................13
Install Lift Rod................................................14
Install Angling Control Rod ............................15
Attaching & Removing the Hitch & Blade
Removing & Attaching Dozer Blade ..............16
Removing & Attaching Hitch ..........................17
Hardware Identification
& Torque Specifications....................................18
NOTE: In these instructions, “left” and “right” are
referred to as seen from the operating position.
© Copyright 2000 Simplicity Manufacturing, Inc.
All Rights Reserved. Printed in USA.
TP 100-2353-02-AT-SMA
Recommended Accessories ..............................1
Safety Rules & Information
General Warnings............................................2
Operating on Slopes........................................2
Preparation ......................................................2
Operating Safety..............................................2
Features & Controls ............................................3
General Operating Instructions
Checks Before Starting....................................4
Engine & Ground Speed Selection..................4
Transporting.....................................................4
Starting & Stopping .........................................4
Changing Angle of the Blade...........................5
Dozing Tips......................................................5
Snow Plowing Tips ..........................................5
Storage .................................................................5
Maintenance & Normal Care Schedule..............6
Schedule for Normal Care ...............................6
Lubricate the Dozer Blade ...............................6
Recommended Accessories
For best performance, it is recommended to use tire chains and two rear wheel weights. A rear-mounted weight
carrier can also be added for additional traction. The maximum weight added to the tractor should not exceed 35
lbs. per wheel, plus 100 additional pounds in the rear weight box.
For operation on slopes greater than 15% (8.5°), Quick Tach Weights, tire chains, and wheel weights are recom-
mended. Never operate on slopes greater than 17.6% (10°).
Required Accessories
A Lift Lever Kit is required for the models covered by this manual, and must be installed as part of hitch installa-
tion.
