Page 17
Always
column
00
Positioning on
the right side
00XX
B XX
Gross weight
15
G XXXXX,XX
01XX
D XX
Date
8
XX.XX.XX
02XX
d XX
Date 1x
8
for pressing tke key just once
03XX
E XX
Orga-data 1
No. 1 XXX... max. 39 pos.
04XX
e XX
Titel Org. 1
blank
05XX
F XX
Orga-data 2
No. 2 XXX... max. 39 pos.
06XX
f XX
Titel Org. 2
blank
07XX
G XX
Orga-data 3
No. 3 XXX... max. 39 pos.
08XX
g XX
Title Org. 3
blank
09XX
K XX
Components
18
K XX XXXXX,XX
10XX
k XX
Total components
16
K-Total XXXXX,XX
11XX
L XX
Current number
15
Current No. XXXXXXX
12XX
N XX
Net weight
16
N XXXXX,XX
13XX
n XX
Net weight total
16
N-Total XXXXX,XX
14XX
P XX
Piece
18
PCS XXXXXXX
15XX
p XX
Total number of pieces
18
Total number of pieces XXXXX,XX
16XX
R XX
Reference weight
17
REF XXXXX,XX
17XX
S XX
Status for break-over points
5
S XXXX
18XX
T XX
Tare weight
15
T XXXXX,XX
19XX
U XX
Time
5
XX:XX
20XX
u XX
Time 1x
5
for pressing tke key just once
21XX
Ü XX
Status for overloading, underloading and standstill
4
U XXX
22XX
W XX
Balance number
2
W X
23XX
0
Attribute 1
Programmation on PC only
24XX
1
Attribute 2
Programmation on PC only
25XX
2
Attribute 3
Programmation on PC only
26XX
3
Attribute 4
Programmation on PC only
27XX
4
Attribute 5
Programmation on PC only
28XX
5
Text 1
Programmation on PC only
29XX
6
Text 2
Programmation on PC only
30XX
7
Text 3
Programmation on PC only
31XX
8
Text 4
Programmation on PC only
32XX
9
Text 5
Programmation on PC only
33XX
,
Linefeed
34XX
ETX/ End of print format
35XX
bxx
Total gross
16
B-Total XXXXX.XX
36XX
txx
Total tare
16
T-Total XXXXX.XX
16
The first programmed data block is displayed (4-digit code number) after the key has
been pressed to activate printing (CAL step 19...24). The incrementing of the tens
column from left to right is achieved using the ”0” key as with user modifications.
Modifications with the numeric keyboard. The displayed value is transferred by pressing
the ”K” key. The next data block is then displayed.
Every print code requires a positioning/beginning of printing. The positioning has to be
additive, that is to say that in case of several data blocks in one line, you should subtract
the positioning of the blocks before. Each line closes with the code ”3.300”. An i.e. line
is programmed with ”3.300”, too. This means, that ”3.300” always creates a new line.
The print image presentation is terminated by ”3.400”. When the values are transferred
using the ”K”-key the display moves forward to the next CAL-step. You return to the
weighing mode by pressing the ”x10”-key.
Print-
code
intern
Print-
code
PC
Print code
Print code
Positioning
Position
data
Block length
Positioning
Positioning
Positioning on the right side
Always column 00
Positioning on
the left side
Settings
Comment
_ Defining the print image:
data transfer
print code
positioning/beginning of printing
Code of 4 positions:
Digit
