User's Manual
Installation overview
The cabinet may be mounted vertically
between wall studs. The width is ideal for
fitting between vertical 2x4 studs, spaced
16 inches apart. It may also be fitted
horizontally.
A cardboard debris shield is supplied
to fill the front aperture and prevent any
dust, paint, or debris from entering during
installation and sheetrock finishing.
Strips of foam material are supplied to
fit between the cabinet and the studs and
sheetrock.
The cabinet should be firmly and
permanently joined to the studwork and
sheetrock using woodscrews and glue.
The woofer baffle assembly is screwed
to the front of the cabinet once the sheet-
rock is in place. A grille frame and grille
are added to finish the installation. A paint
shield is supplied so that you can easily
paint the grille at the same time as the
walls are painted.
Unpacking
Two people are required to gently lift out
the cabinet and the baffle assembly from
their shipping boxes. Remove all the
packing material.
Your Sunfire subwoofer should reach
you in perfect condition. If you do notice
any shipping damage, please contact
Sunfire immediately. Make sure that you
keep your sales receipt. It is the only way
to establish the duration of your Limited
Warranty and it may come in useful for
insurance purposes.
The serial number for the SubRosa
subwoofer is printed on the front label of
the woofer assembly.
Contents of each package
SRS–210W-C cabinet
• Cabinet assembly
Dimensions 44.50" x 14.25" x 3.5"
1,130.3 mm x 362 mm x 88.9 mm
Weight 23.30 lb (10.6 kg)
• Debris shield
• 12 foam strips 1" x 5"
• 8 foam strips 1" x 8"
• Plastic rivets for debris shield
• 12 wood screws
SRS–210W-B baffle assembly
• Baffle assembly
Dimensions 26.75" x 11.75" x 3.25"
679.5 mm x 298.5 mm x 82.6 mm
Weight 29 lb (13.2 kg)
• 14 Allen head screws and washers
(8-32 x 1.25")
SRS–210W-G grill assembly
• Grille frame
Dimensions 28.80" x 13.8" x 0.7"
731.5 mm x 350.5 mm x 17.78 mm
(includes drywall spacer)
Weight 2.00 lb (0.9 kg)
• Grille
Dimensions 26.5" x 11.5" x 0.75"
673.1 mm x 292.1 mm 19.1 mm
Weight 0.6 lb (0.27 kg)
• Paint shield
• 12 Allen head screws
SRA–2700EQ amplifier
• SubRosa amplifier
Dimensions 1.75" (1U) x 17" x 15"
44.5 mm x 41.8 mm x 81 mm
Weight 18.4 lb. (8.35 kg)
• Room measurement microphone
with stand and cord
• AC power cord
• 2 rack-mount brackets
Introduction
5
