* Click the Play( )/Stop( ) button in the table below to view the video file.
Screen
Adjustment
Description Play/Stop
Install To tailor the picture to the installation location, you can invert the projected images
vertically/horizontally.
1) Front-Floor : Normal Image
2) Front-Ceiling : Horizontal/Vertical Reversed Image
3) Rear-Floor : Horizontally Reversed Image
4) Rear-Ceiling : Vertically Reversed Image
V-Keystone If video scences are distorted or tilted, you can compensate for this using the vertical
Keystone function.
▶ As the Vertical Keystone function compensates for screen distortions via software,
we recommend installing the projector so that no screen distortions occur in the
horizontal and vertical directions, rather than using the vertical keystone function.
Test Pattern Generated by the projector itself. Utilized as standard to optimize the installation of the
projector.
1) Crosshatch : You can check whether the picture is distorted or not.
2) Screen Size : You can refer to picture format sizes such as 1.33 : 1 or 1.78 : 1.
3) Red : Red Screen, only for color adjustment.
4) Green : Green Screen, only for color adjustment.
5) Blue : Blue Screen, only for color adjustment.
6) White : White Screen, only for color adjustment.
7) 6500K_White : White Screen, brings out the white tones for a more real white.
▶ The Red/Green/Blue colors of the test patterns are only for the color adjustment
procedures, and may not comply with the actual colors displayed during video
playback.
PC Eliminates or reduces noise that causes unstable screen quality, such as screen
