270 5486.4 4114.8 9457 7880 686
280 5689.6 4267.2 9809 8173 711
290 5892.8 4419.6 10160 8466 737
300 6096.0 4572.0 10512 8759 762
This projector is designed to show images optimally on a 80 ~ 120 inch sized screen.
A. Screen
Z: Throw Distance
Y': Distance from Lens Center to Image Bottom
Setting up the PC Environment - Check the following items before connecting your PC to your projector.
1. Click the right mouse button on the Windows desktop
and click on [Properties].
tab will appear.
2. Click on [Settings] tab and set the by
referring to as described in the display mode table
supported by this projector.
You do not have to change setup.
3. Press the [Advanced] button.
Another property window will appear.
4. Click on [Monitor] tab and set the by referring
to as described in the Supported
