20 U10 Family Product Manual, Rev. A
Figure 3. Mounting dimensions—top, side and end view
1.00 ± 0.028
(25.4 ± 0.7)
3.72 ± 0.03
(94.5 ± 0.8)
4.00 ± 0.02
(101.6 ± 0.5)
3.750 ± 0.010
(95.25 ± 0.25)
5.75 ± 0.03
(146.1 ± 0.8)
4.000 ± 0.010
(101.60 ± 0.25)
3X.250 ± .015
(6.35 ± 0.38)
(both sides)
2.23 ± 0.03
(56.6 ± 0.8) 0.230 ± 0.015
(5.84 ± 0.38)
0.180 ± 0.015
(4.57 ± 0.38)
2.362 ± 0.010
(59.99 ± 0.25)
1.750 ± 0.010
(44.45 ± 0.25)
3X 6-32 UNC-2B
max. insertion depth
0.14 (3.6) both sides
4X 6-32 UNC-2B
max. insertion
depth 0.22 (5.6)
0.125 +0.030, –0.005
(3.18 +0.76, –0.13)
0.630 +0.030, –0.005
(16.00 +0.76, –0.13)
Note: Dimensions are shown in inches (mm).
2.375 +0.030, –0.005
(60.33 +0.76, –0.13)
Recommended
case temperature
measurement location Recommended
case temperature
measurement location
