Smooth Fitness 9.25HR User Manual
Page 16
SMOOTH 9.25HR MOTORIZED TREADMILL
Visit us at: www.smoothfitness.com
16
ASSEMBLY
STEP 5:
Remove the Bracket Screw (135) from Console Tray Fixing Plate (21). Attach the Console Tray (22) to the Console Housing
(3) and secure by screwing the Bracket Screw (135) through the Console Tray Fixing Plate (21) and into the Console
Housing (3), as shown in FIG3.
22
36
30
135
3
21
135
21
FIG3
