Hooking up the system securely
1 To AM loop antenna
2 To FM lead antenna
3 To subwoofer
4 To front speaker (left)
5 To front speaker (right)
a)
The FM 75
Ω COAXIAL jack varies according to
models.
b)
MHC-GTZ5, MHC-GTZ4 / GTZ4i, MHC-GTZ3 /
GTZ3i and LBT-GTZ4i only.
c)
The VOLTAGE SELECTOR varies according to
models.
Getting Started
a)
c)
b)
1
3
4
5
A
B
C
D
E
ANTENNA
PC IN
SUBWOOFER
VOLTAGE
SELECTOR
FRONT SPEAKER
2
F
