Outdoor unit – Samsung AS09CM2X User Manual

Page 5

background image

E-

5

Air Inlet(Rear)

Air Outlet

Connection Valve
(inside)

Outdoor Unit

AS09CM1(2)X

AS12CM1(2)X

Air Inlet(Rear)

Air Outlet

Connection Valve

Outdoor Unit

AS18CM1(2)X

AS24CM1(2)X
