Simplicity Manufacturing 616RT User Manual
Page 13
11
TP-400-2488-00-RT-S
Transmission Group
1
1716788
1
TRANSMISSION ASSEMBLY
2
1716780
8
CAPSCREW, Hex Flagne Head, 5/16”- 18 x 3/4”
3
1716789
2
GASKET, Housing & Transmission Cover
4
1716790
2
PLUG, Pipe Socket Head 1/4”- 18, Oil Check
5
1716791
4
SEAL, Housing 1506
6
1716794
1
PLUG, Oil Fill
7
1716724
1
COVER, Transmission Wheel Housing
8
1716792
2
GASKET, Bearing Cap Front, Rear
9
1716799
1
GASKET KIT, Oil Seal (Includes Ref. Nos. 3, 5, and 8)
10
1716798
3
CAPSCREW, Hex Flange Head, 1/4”- 20 x 3/4 “
11
1716797
1
SEAL, Oil Drive Shaft
12
1716796
1
CAP, Front Bearing
13
1716793
1
CAP, Rear Bearing
14
1716795
3
CAPSCREW, Hex Flange Head, 1/4”- 20 x 7/8”
REF NO.
PART NO.
QTY.
DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693704
616RT, 6HP Rear Tine Tiller
