Simplicity Manufacturing 616RT User Manual
Page 11
9
TP-400-2488-00-RT-S
Shifting Mechanism Group
1
1721531
2
CAPSCREW, 5MM x .8 x 16MM RT
2
1719063
2
C-CLAMP
3
1935048
9
NUT, Hex Flagne 5/16”- 18 Two, Way Lock
4
1721509
1
BRACKET, Cable Mount
5
1716732
2
NUT, Hex Nylok
6
1716801
2
BAR, Shift Mounting
7
1921977
6
CAPSCREW, 5/16”- 18 x 1-1/4” G5
8
1716702
2
PIN, Link Forward/Reverse
9
1716703
1
PIN, Cotter
10
1716804
1
ARM, Forward Idler
11
1924940
3
WASHER, 3/8”
12
1716803
1
PULLEY, Forward Idler
13
1916950
2
NUT, HEX 3/8”- 16
14
1716728
2
YOKE, Cable
15
1716704
2
BUSHING, Pivot, 5/16”
16
1921978
2
CAPSCREW, 5/16”- 18 x 2” G5
17
1721507
1
PULLEY, Reverse
18
1721508
1
ARM, Idler Reverse
19
1716802
1
SPRING, Idler Arm
REF NO.
PART NO.
QTY.
DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693704
616RT, 6HP Rear Tine Tiller
