Part # 4523343 Rev 1 (02/12/08) Page 5
DIMENSIONS AND SPECIFICATIONS continued
Base Model Designations & Total Input Rates
Model # Description
Input BTU/Hr
Natural
Gas
Propane
Gas
X24-4S 24” (610mm) nominal size unit, 4 open burners, storage base 120,000 104,000
X24-4L 24” (610mm) nominal size unit, 4 open burners, space saver oven 145,000 129,000
X36-6S 36” (914mm) nominal size unit, 6 open burners, storage base 180,000 156,000
X36-6R 36” (914mm) nominal size unit, 6 open burners, standard oven 213,000 185,000
X60-10SS 60” (1524mm) nominal size unit, 10 open burners, 2 storage bases 300,000 260,000
X60-10RS 60” (1524mm) nominal size unit, 10 open burners, standard oven, storage base 333,000 289,000
X60-10RR 60” (1524mm) nominal size unit, 10 open burners, 2 standard ovens 366,000 318,000
X60-6R24SS
60” (1524mm) nominal size unit, 6 open burners, 24” (610mm) Raised Griddle/Broiler,
2 storage bases
203,000 189,000
X60-6R24RS 60” (1524mm) nominal size unit, 6 open burners, 24” (610mm) Raised Griddle/Broiler,
standard oven, storage bases
246,000 218,000
X60-6R24RR 60” (1524mm) nominal size unit, 6 open burners, 24” (610mm) Raised Griddle/Broiler,
2 standard ovens
279,000 247,000
Rates are for installations up to 2000’ (610m) above sea level
INTRODUCTION
1 . Check crate for possible damage sustained during transit .
Carefully remove unit from crate and again check for
damage . Any damage to the appliance must be reported
to the carrier immediately .
2 . The wires for retaining packing material must be
removed from units . Any protective material covering
stainless steel parts must also be removed .
3 . All equipment is supplied with 6” (152mm) legs unless
specified to be dais for cove base mounting, casters or
deck mount flanged feet . 60” (1524mm) wide units have
legs factory mounted . Base mounting is required when
range is being installed on a combustible floor .
4 . The type of gas and supply pressure that the equipment
was set-up for at the factory is noted on the rating plate
and on the packaging . This type of gas supply must be
used .
5 . Do not remove permanently affixed labels, warnings or
rating plates from the appliance, for this may invalidate
the manufacturer’s warranty .
Rating Plate
All burner input rates are shown on the rating plate, which is
located behind the lower front drop down panel under the
oven door .
