ATTENTION !
To ensure correct parts supply,please let us know followings,
when you make service parts order:
1.Part No. 2.Description 3.Q'ty 4.Volts-Hz-Ph 5.Product Model No.
* 1 623 165 4371 Heat Exch Ass'y
1 854-0-4124-14200
* 2 623 191 9586 Switch Ass'y SW-KH3672R
1 8FA-0-5152-02500
3 623 301 0724 Elec. Wiring Diagram
1 8FA-2-5250-17700
* 4 623 159 7197 Thermistor Ass'y PBC-41E-S4
1 854-0-5259-53000
* 5 623 191 6783 Fuse MT3 5A
2 1FJ-4-S3A0-03900
6 623 192 0049 Flap
1 854-2-1515-10211
7 623 096 4617 Cover Plate
1 854-2-2342-33310
8 623 096 4600 Mounting Plate, Fan Motor
1 854-2-2513-18110
9 623 096 3931 Drain Pipe Ass'y
1 854-0-4297-13000
10 623 159 7159 Hook Plate
1 854-2-1130-15100
* 11 638 013 8319 Fan Ass'y FRS-11099-AA
1 854-0-2501-23500
12 623 123 8878 Cushion Rubber
2 854-2-2534-15600
* 13 623 094 4466 Bearing Housing Ass'y
1 852-0-2510-12800
* 14 623 159 7203 Thermistor Ass'y PBC-41E-S4
1 854-0-5259-53100
15 638 015 9109 Cover,Elec.Component Box
1 854-2-5304-49201
16 623 129 8537 Cover Terminal
1 854-2-5305-13201
17 623 184 6011 Cover UKT25W-4D
1 854-2-5376-00700
* 18 623 159 7289 Fan Motor Ass'y UF4Q-31A6P
1 854-0-5202-31700
* 19 623 159 7166 Transformer Ass'y ATR-IIK244B
1 854-0-5263-19200
20 623 092 9647 Fastener Blade
1 854-2-1521-11601
21 638 003 7209 Mounting
2 852-2-1514-44002
22 623 129 7363 Mounting
1 852-2-1514-42601
23 623 192 0063 Ornamental Plate
1 854-2-1308-25011
* 24 623 191 9623 Thermistor Ass'y KTEC-35-S6
1 854-0-5259-529H1
25 623 191 9692 Frame Filter Ass'y
3 854-0-1302-14411
26 623 130 7000 Mounting Plate
1 854-2-5312-63600
27 638 015 9116 Mounting Plate
1 854-2-5309-11501
* 28 623 107 3882 Synchronized Motor M2EA24ZA01
1 528-0-0000-07006
* 29 623 192 1572 Circuit Board Ass'y CR-TH2672
1 854-9-9536-05306
30 623 192 0070 Grille
1 854-2-1150-10511
* 31 638 007 0572 Fixed Capacitor CMPS UP44B185JMF
1 4-2239-56845
32 623 096 4983 Partition Plate
1 854-2-2314-228H2
* 33 623 192 0100 Drain Pan Ass'y
1 854-0-2301-359H4
* 34 638 018 1421 Terminal Base UKT25W-4J(C)
1 1FJ-4-J3A0-07300
* 35 623 160 3881 P.C.B.Ass'y CR-KH1U
1 854-0-5178-25600
36 623 192 2111 Elec Component Box Ass'y
1 854-0-5311-06901
37 623 103 8201 Cam Ass'y
1 852-9-9536-03518
38 623 192 0094 Ornamental Plate
1 854-2-1308-251H9
39 623 192 0087 Frame Ass'y
1 854-2-2250-101K5
40 623 050 5674 Mounting Plate
1 852-2-2309-33301
41 638 015 9123 Mounting Plate
1 854-2-5309-11601
42 638 015 1189 Mounting Plate
1 854-2-2360-76601
43 623 050 5698 Mounting Plate
1 852-2-2309-33501
44 623 129 8506 Mounting Plate
1 854-2-4134-47601
45 623 050 5704 Mounting Plate
1 852-2-2309-33701
46 623 192 0117 Mounting Plate, Blade
1 854-2-2524-10811
47 638 018 9465 Mounting Plate
2 854-2-2360-60101
48 623 096 4624 Cover Plate
1 854-2-2342-33410
49 623 096 4952 Heater Ass'y AH-KH2412
1 851-0-0052-038H1
50 623 092 9531 Mounting Plate
1 854-2-4134-36301
Key
No.
Part No.
Description
Q'ty
Reference No.
KHHS2672R
INDOOR UNIT
NOTE:
Metal and plastic parts will be supplied basically
with necessary heat insulation pads or packing.
Each key number with an asterisk (*) means the
recommended service parts.
- 3 -
