HANDLES & CONTROLS (2002 & EARLIER)
Footnotes:
TP 400-5001-5-WB-N
Manual No.
7006135
21" STEEL DECK WALK BEHIND MOWER
"MR" SERIES 17
5
Part No
Description
Item
Qty
Note
1
7074254
1
HANDLE, Upper
Was 72931 (used on All)
2
7036350
1
HANDLE, Middle- 1990
used on All
3
7046502
1
HANDLE, Lower Left Hand
used on All
4
7035342
1
HANDLE, Lower Right Hand
used on All
5
7047011
1
BAIL, Blade Control
used on All
6
7034872
1
CLIP, Blade Control
used on All
7
7072933
1
CABLE, Blade Control (49-1/4” long)
used on All
8
7032826
1
HANDLE, Wheel Drive
used on Self-Propelled
9
7014307
1
GRIP, Wheel Drive Handle
used on Self-Propelled
--
7029775
1
GRIP,Wheel Drive Handle (Euro)
used on Self-Propelled (Euro)
10
7072932
1
CABLE, Clutch Pull (Z-Bend, 38-5/8” long)
used on Self-Propelled
11
7012121
1
COVER, Vinyl
used on Self-Propelled
12
7012122
1
SPRING, Clutch
used on Self-Propelled
13
7041871
1
SECTOR, Speed
used on Self-Propelled
14
7091714
1
BOLT, 5/16-18 x 1” Square Neck Carriage GR 5
Was 91238 (used on All)
15
7012093
1
SPRING, Speed Control
used on Self-Propelled
16
7090188
1
WASHER, 3/8” Flat
used on Self-Propelled
17
7023801
1
GRIP, Speed Control Handle
Was 29383, used on Self-
Propelled
18
7024087
1
DECAL, Speed Select
used on Self-Propelled
--
7029783
1
DECAL, Speed Select (Euro)
used on Self-Propelled (Euro)
19
7032408
1
GUIDE, Lower V-Belt
used on Self-Propelled
20
7023790
1
ROD, Transfer
used on Self-Propelled
--
7051698
1
ASSY., Transfer Rod (Incl. indented items below)
used on Self-Propelled (Euro)
20a
7015752
1
LINK, Transfer
used on Self-Propelled (Euro)
20b
7015753
1
BALL JOINT, 1/4-28
used on Self-Propelled (Euro)
20c
7090095
1
NUT, 1/4-28 Hex
used on Self-Propelled (Euro)
21
7010937
1
CLIP, Transfer Rod 1/4”
used on Self-Propelled
22
7090895
1
TEE-NUT, 5/16-18
used on Self-Propelled
23
7012114
1
BUSHING, Differential
used on Self-Propelled
24
7090595
2
BOLT, 5/16-18 x 3/4” Hex Flange Lock GR5
used on All
25
7090238
1
SCREW, 5/16-24 x 1” Hex Head Cap GR5
used on All
26
7090799
1
BOLT, 5/16-18 x 5/8” Short Neck Carriage GR5
Was 91026 (used on All)
27
7091601
10
NUT, 5/16-18 Hex Flange Lock GR5
Was 91070 (used on All)
28
7046202
1
BRACKET, Speed Control Rod
used on Self-Propelled
29
7024641
2
WIRE TIE, 1.29” Long (Black)
used on All
30
7091740
4
SCREW, 5/16-18 x 1-7/8” Curved Head GR2
Was 91189 (used on All)
31
7035744
4
T-KNOB, 5/16-18 (BLACK)
used on All
