Snapper MR SERIES 17 WMR216017BV - Manual (Page 15)

FRONT WHEEL BRACKET
Footnotes:
TP 400-5001-5-WB-N
Manual No. 7006135 21" STEEL DECK WALK BEHIND MOWER
"MR" SERIES 17
15
Part No Description Item Qty Note
1 7051886 1 ASSEMBLY, Right Wheel Arm (Consists of items 2, 3, 4, 5A &
6)
-- 7051885 1 ASSEMBLY, Left Wheel Arm (Consists of items 2, 3, 4, 5B &
6)
2 7015761 2 BOLT, 5/16-18 Hex Washer Face Shoulder
3 7012325 2 LATCH, Height
4 7027702 2 GRIP, Latch
5A 7031017 1 ARM, Right Wheel (Round Hole)
5B 7031016 1 ARM, Left Wheel (Square Hole) not shown
6 7011791 2 RETAINER, 5/16” Bolt (Black)
7 7091601 2 NUT, 5/16-18 Hex Flange Lock Was 91070
8 7074702 1 WELDMENT, Front Wheel Bracket Was 41770
-- 7074702 1 WELDMENT, Front Wheel Bracket used on MR216517B &
MRP216517B models
9 7021119 1 AXLE
