Appendix E – RS-232 communication
56
RS-232
COMMUNICATION
color Temp User-
Read CTU CTU??
Gamma-Write TGA 0 7 3 Gamma 1.0 == TGA00
Gamma 1.5 == TGA01
Gamma 2.2 == TGA02
Gamma 2.8 == TGA03
Gamma User Mode ==
TGA04
Gamma-Read TGA TGA??
Color Mode-Write CMO 0 3 3 Color Mode Movie ==
CM000
Color Mode Sports ==
CM001
Color Mode VIvid ==
CM002
Color Mode Normal ==
CM003
Color Mode-Read CMO CMO??
Clock-Write CLO 0 99 50 Clock 50 == CLO50 PC Only
Clock-Read CLO CLO?? PC Only
Phase-Write HAS 0 31 0 Phase 0 == HAS PC Only
Phase-Read HAS HAS?? PC Only
Menu Picture Reset
MPR MPR Menu Picture Reset ==
MPR00
OSD H Position-
Write OPH 100 0 OSD H Position 0 ==
OPH00
OSD H Position-
Read OPH OPH??
OSD V Position-
Write OPV 0 100 0 OSD V Position 0 ==
OPV00
Lamp Timer Reset
LTR LTR Lamp Timer Reset Yes ==
LTR01
Color Matrix Red-
Write CMR 0 30 30 Color Matrix Red 30 ==
CMG30
Color Matrix Red-
Read CMR CMR??
Color Matrix Green-
Write CMG 0 30 30 Color Matrix Green 30 ==
CMG30
Color Matrix Green-
Read CMG CMG??
Color Matrix Blue-
Read CMB 0 30 30 Color Matrix Blue 30
==CMB30
Color Matrix Blue-
Read CMB CMB??
Color Matrix Cyan-
Read CMC 0 30 30 Color Matrix Cyan 30
==CMC30
RS232 Control
Function
Command
Title
Min
Value
Max
Value
Default
Value
Example Notes
