Smooth Fitness 5.45 User Manual
Page 9
5.45 MOTORIZED TREADMILL
8
COMPLETE PARTS LIST
Part No.
Description
Qty.
Order No.
400
Complete Base Frame Components
401
Base Frame
1
5.45‐401
402
Rubber Cushion
2
5.45‐402
403
Rubber Cushion
2
5.45‐403
404
Power Switch Plate Base
1
5.45‐404
405
Power Switch Plate Cover
1
5.45‐405
406
Power Switch Plate
1
5.45‐406
407
Power Breaker
1
5.45‐407
408
Power Switch
1
5.45‐408
409
Front Caster
2
5.45‐409
410
Cushion
2
5.45‐410
411
Foot Locker
1
5.45‐411
412
Transportation Wheel Bracket
1
5.45‐412
413
Spring
1
5.45‐413
414
Transportation Wheel
1
5.45‐414
415
Fold Up Locker
1
5.45‐415
416
Spring Of The Fold Up Locker Assembly
1
5.45‐416
500
Complete Motor Components
501
Motor Hood Top
1
5.45‐501
502
Driving Motor
1
5.45‐502
503
Motor Holder
1
5.45‐503
504
Driving Belt
1
5.45‐504
505
Control Board
1
5.45‐505
506
Elevation Support Tube
1
5.45‐506
507
Elevation Support Tube End Cap
4
5.45‐507
508
Elevation Motor
1
5.45‐508
509
Elevation Gear Sleeve
1
5.45‐509
510
Fold Up Support
1
5.45‐510
511
Shock
1
5.45‐511
512
Wheel
1
5.45‐512
513
Plastic Clamp ‐ Top
2
5.45‐513
514
Plastic Clamp ‐ Bottom
2
5.45‐514
515
Elevation Support
2
5.45‐515
516
Motor Hood ‐ Left
1
5.45‐516
517
Motor Hood ‐ Right
1
5.45‐517
518
Motor Bottom Cover
1
5.45‐518
519
Relay board
1
5.45‐519
520
Rubber Cushion
2
5.45‐520
600
.
Complete Running Deck Components
601
Running Belt
1
5.45‐601
602
Side Rail
2
5.45‐602
603
Running Deck
1
5.45‐603
604
Side Rail End Cap ‐ Left
1
5.45‐604
605
Side Rail End Cap ‐ Right
1
5.45‐605
606
Cushion Pad
8
5.45‐606
