E-38
Maintenance & Tr
oubleshooting
Air Filter Maintenance
4 Replace the filter cover.
Insert the tab on the end of the filter cover into the
filter cover opening and press the filter cover into
position.
3 Clean the air filter.
Clean the dust off the air filter and cover with a
vacuum cleaner extension hose.
Tab
4 5 Replace the air filter. Replace the filter cover.
Insert the tab on the end of the filter cover into the
filter cover opening and press the filter cover into
position.
1 Put the new air filter into position.
2 Put the air filter stopper back into position.
Replacing the air filter
Tab
1 3 2 Remove the filter cover.
1 Remove the air filter stopper.
2 Remove the air filter.
Turn over the projector. Press the
tab and remove the filter cover in
the direction of the arrow.
Remove the air filter.
Tab
Disconnect the power
cord.
Unplug the power cord from the
AC socket.
• Be sure the filter cover is securely installed. The power will not turn on unless it is correctly installed.
