SSC-M383 SSC-M383CE SSC-M388CE SSC-M183 SSC-M183CE SSC-M188CE
Camera
Image device 1/3-type CCD with Exwave HAD technology
Number of effective pixels 370,000 (768 x 494) 430,000 (752 x 582) 250,000 (510 x 492) 291,000 (500 x 582)
(H x V)
Auto Gain Control
TURBO/OFF switchable
White balance mode ATW
Lens type CS-mount, DC/Video servo auto iris
CCD iris ON/OFF switchable, ON/OFF switchable, 1/50 to 1/100,000 s ON/OFF switchable, ON/OFF switchable, 1/50 to 1/100,000 s
1/60 to 1/100,000 s 1/60 to 1/100,000 s
Back-Light Compensation (BLC) ON/OFF switchable
Analog video output BNC x 1, 1.0 Vp-p, 75 Ω, Sync negative
Signal system EIA CCIR EIA CCIR
Sync system Internal/AC Line lock AC Line lock Internal/AC Line lock AC Line lock
Horizontal Resolution 570 TV lines 380 TV lines
S/N ratio More than 50 dB (AGC OFF, WEIGHT ON)
Minimum illumination 0.07 lx (50IRE, F1.2, Turbo AGC ON) 0.06 lx (50IRE, F1.2, Turbo AGC ON)
General
Mass approx. 360 g (13 oz) approx. 390 g (14 oz) approx. 360 g (13 oz) approx. 390 g (14 oz)
Dimensions (W x H x D) 60 x 54 x 120 mm (2 3 / 8 x 2 1 / 4 x 4 3 / 4 inches)
Power requirements AC 24 V ±10%, 60 Hz AC 24 V ±10%, 50 Hz AC 220 to 240 V ±10 %, AC 24 V ±10%, 60 Hz AC 24 V ±10%, 50 Hz AC 220 to 240 V ±10 %,
or DC 12 V ±10% or DC 12 V ±10 % 50 Hz or DC 12 V ±10% or DC 12 V ±10% 50 Hz
Power consumption 2.6 W 2.5 W
Operating temperature -10 to 50°C (14 to 122°F)
Storage temperature -40 to 60°C (-40 to 140°F)
Supplied accessories
Lens mount cap, Operating instructions Lens mount cap, Lens mount cap, Operating instructions Lens mount cap,
Operating instructions, Operating instructions,
AC power cable AC power cable
Analog Cameras (B/W)
SSC-CD73V SSC-CD73VP SS-CD73VT SSC-CD43V SSC-CD43VP SSC-CD43VT
Camera
Image device 1/4-type Super HAD CCD
Number of effective pixels 370,000 (768 x 494) 430,000 (752 x 582) 370,000 (768 x 494) 430,000 (752 x 582) 370,000 (768 x 494)
(H x V)
Auto Gain Control
TURBO/OFF switchable
White balance mode ATW
Lens type Vari-focal lens, CS-mount, DC servo auto iris
Focal length f=3.0 to 8.0 mm
View angle W=84.6°(D), 66.6°(H), 49.3°(V) W=84.7°(D), 66.6°(H), 49.3°(V)
T=33.8°(D), 27°(H), 20.2°(V) T=33.6°(D), 26.9°(H), 20.1°(V)
CCD iris ON/OFF switchable, ON/OFF switchable, ON/OFF switchable, 1/60 to 1/100,000 s ON/OFF switchable, ON/OFF switchable,
1/60 to 1/100,000 s 1/50 to 1/100,000 s 1/50 to 1/100,000 s 1/60 to 1/100,000 s
Minimum object distance 0.2 m
Back-Light Compensation (BLC) ON/OFF switchable
Analog video output BNC x 1, 1.0 Vp-p, 75 Ω, Sync negative UTP x 1, 1.0 Vp-p, BNC x 1, 1.0 Vp-p, 75 Ω, Sync negative UTP x 1, 1.0 Vp-p,
100 Ω, Sync negative 100 Ω, Sync negative
Signal system NTSC PAL NTSC PAL NTSC
Sync system Internal/AC Line lock
Horizontal Resolution 480 TV lines – 480 TV lines –
S/N ratio More than 50 dB (AGC OFF, WEIGHT ON)
Minimum illumination Color: 0.9 lx (50IRE, F1.0, AGC ON), B&W: 0.2 lx (50IRE, F1.0, AGC ON) Color: 0.8 lx (50IRE, F1.0, AGC ON)
General
Mass approx. 1,150 g (2 lb 10 oz) approx. 440 g (16 oz)
Dimensions (W x H x D) 147 x 111 x 148 mm (5 7 / 8 x 4 3 / 8 x 5 7 / 8 inches) 121 x 107 x 123 mm (4 7 / 8 x 4 1 / 4 x 4 7 / 8 inches)
Power requirements AC 24 V ±10%, 60 Hz or AC 24 V ±10%, 50 Hz or AC 24 V ±10%, 60 Hz or DC 12 V ±10% AC 24 V ±10%, 50 Hz or AC 24 V ±10%, 60 Hz or
DC 12 V ±10% 12 V ±10% 12 V ±10% 12 V ±10%
Power consumption 3.6 W 3.3 W
Operating temperature -20 to 50°C (-4 to 122°F)
Storage temperature -40 to 60°C (-40 to 140°F)
Supplied accessories
Screw TP4 x 30 (4), Monitor cable, Screwdriver, Screw TP4 x 30 (2), Dome cover screw, Monitor cable, Operating Instructions
External control terminal connector, Operating Instructions
Analog Cameras
