29
SSC-DC590 SSC-DC593 SSC-DC593P SSC-DC598P
Camera
Image device 1/3-type CCD with DynaView technology
Number of effective pixels 370,000 (768 x 494) 430,000 (752 x 582)
(H x V)
Auto Gain Control
NORMAL/TURBO/MANUAL/OFF selectable
White balance mode ATW pro/ATW/3200K/5600K/MANUAL/DUAL WB selectable
Lens type CS-mount, DC/Video servo auto iris
CCD iris ON/OFF switchable, 1/60 to 1/100,000 s ON/OFF switchable, 1/50 to 1/100,000 s
Back-Light Compensation (BLC) DYNAVIEW/SPOT/WEIGHT/OFF selectable
Day/Night function Auto/External/Color/B&W selectable
Analog video output BNC x 1, 1.0 Vp-p, 75 Ω, Sync negative
Signal system NTSC PAL
Sync system Internal/VS/VD Internal/AC Line lock
Horizontal Resolution 480 TV lines
S/N ratio More than 50 dB (AGC OFF, WEIGHT ON)
Minimum illumination Color: 0.8 lx (50IRE, F1.4, Turbo AGC ON), B&W: 0.07 lx (50IRE, F1.4,Turbo AGC ON)
General
Mass approx. 500 g (1 lb 2 oz)
Dimensions (W x H x D) 70 x 57 x 129 mm (2 7 / 8 x 2 1 / 4 x 5 1 / 8 inches)
Power requirements Multiplexing with the AC 24 V ±10%, 60 Hz or AC 24 V ±10%, 50 Hz or AC 220 to 240 V ±10%, 50 Hz
YS-W170A/W270A or DC 12 V ±10% DC 12 V ±10%
DC 12 V ±10%
Power consumption 5.8 W 5.6 W
Operating temperature -10 to 50°C (14 to 122°F)
Storage temperature -40 to 60°C (-40 to 140°F)
Supplied accessories
Lens mount cap, Operating instructions, Menu operations Lens mount cap, Operating
instructions, Menu operations,
AC power cable
Analog Cameras
SSC-DC573 SSC-DC573P SSC-DC578P
Camera
Image device 1/3-type CCD with DynaView technology
Number of effective pixels 370,000 (768 x 494) 430,000 (752 x 582)
(H x V)
Auto Gain Control
NORMAL/TURBO/MANUAL/OFF selectable
White balance mode ATW pro/ATW/3200K/5600K/MANUAL/DUAL WB selectable
Lens type CS-mount, DC/Video auto iris
CCD iris ON/OFF switchable, 1/60 to 1/100,000 s ON/OFF switchable, 1/50 to 1/100,000 s
Back-Light Compensation (BLC) DYNAVIEW/SPOT/WEIGHT/OFF selectable
Day/Night function –
Analog video output BNC x 1, 1.0 Vp-p, 75 Ω, Sync negative
Signal system NTSC PAL
Sync system Internal/AC Line lock
Horizontal Resolution 480 TV lines
S/N ratio More than 50 dB (AGC OFF, WEIGHT ON)
Minimum illumination 0.8 lx (50IRE, F1.4, Turbo AGC ON)
General
Mass approx. 480 g (1 lb 1 oz)
Dimensions (W x H x D) 70 x 57 x 129 mm (2 7 / 8 x 2 1 / 4 x 5 1 / 8 inches)
Power requirements AC 24 V ±10%, 60 Hz or DC 12 V ±10% AC 24 V ±10%, 50 Hz or DC 12 V ±10% AC 220 to 240 V ±10%, 50 Hz
Power consumption 4 W
Operating temperature -10 to 50°C (14 to 122°F)
Storage temperature -40 to 60°C (-40 to 140°F)
Supplied accessories
Lens mount cap, Operating instructions, Menu operations Lens mount cap, Operating instructions,
Menu operations, AC power cable
