Sony C1VPK User Manual
Page 12

1-9
PCG-C1VP/C1VPK (UC)
Confidential
16. LCD 1210 Assy
15. Bezel Assy
8
Undo ten claws and
remove the bezel assy.
7
M2X5
3
M2X6
6
Blind Rubber
(Left)
2
Blind Rubber
(Lower)
1
Undo three claws
and remove the hinge
cover assy.
1
Undo three claws and
remove the hinge cover assy.
5
M2X5
4
Blind Rubber (Right)
3
M2X6
2
Blind Rubber
(Lower)
LCD 1210 Assy
2
LCD Harness
3
Harness
1
M2X4
